Solis S2620
Solis
S2620
Shift with Ease, Work with Power
The Power Of Japanese Technology
Solis S2620 features a comfortable and spacious cabin that provides a great view of the working area. It comes with a reliable and efficient engine that delivers impressive power and performance, making it the perfect choice for small to medium-sized farms.
3 CYLINDER MITSUBISHI ENGINE
MECHANICAL TRANSMISSION 6F+2R FOR SPEED PERFECTION
1DA AUXILIARY HYDRAULIC CIRCUIT
SLEEK & STYLISH BONNET
Technical Specifications
| ENGINE | |
| Engine Type | MHI Engine |
| HP Category | 26 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 1318 |
| Rated RPM | 2700 |
| Air Cleaner | Dry Type with Clogging Sensor |
| Cold Start | Standard |
| Max Torque (Nm) | 76.3 Nm |
| Exhaust | Downdraft Exhaust |
| Muffler | Under-hood |
| TRANSMISSION | |
| Drive | 4WD |
| Clutch | Single Clutch |
| Gearbox | 6F+2R |
| Front Axle | 4WD |
| Transmission | Sliding Mesh |
| SPEED (FORWARD) | |
| Maximum Speed (Km/Hr) | 15.58 @ 2700 erpm |
| Minimum Speed (Km/Hr) | 1.67 @ 2700 erpm Speeds may vary with other tyres |
| BRAKES | |
| Brakes | Oil Immersed Brakes |
| Type of Actuation | Mechanical |
| Parking Brake | Independent |
| DIFFERENTIAL LOCK | |
| Differential Lock | Mechanical, Foot Operated |
| PTO | |
| PTO (RPM) | 540/1000 |
| PTO (Actuation) | Mechanical |
| STEERING | |
| Steering | Power |
| ELECTRICAL | |
| Battery | 12V, 65Ah |
| Alternator | 12V, 42Amp |
| Seven Pin Trailer Socket | Output 12V |
| HYDRAULICS | |
| 3 Point Linkage | Cat 1-N |
| Stay Bars | Anchor Chain |
| Hydraulic Lifting Capacity | 6000kg |
| Auxiliary Hydraulic Circuit | 1DA |
| SAFETY SWITCH | |
| Clutch Safety Switch | Standard |
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
| CAPACITY (Ltrs.) (+/-5%) | |
| Fuel Tank (Ltr.) | 26 |
| TURNING RADIUS | |
| Without Brakes (m) | 3.1 |
| TYRE | |
| Front | 6.00 – 12 |
| Rear | 8.30 – 20 |
| DIMENSION & WEIGHT (+/-5%) | |
| Weight (kg) | 1020 |
| Wheel Base (mm) | 1560 |
| Total Length (mm) | 2760 |
| Total Width (mm) | 1075 |
| Height (mm) Up to ROPS | 1955 |
| Min. Ground Clearance (mm) | 240 |
| Front Track (mm) | 885 |
| Rear Track (mm) | 835 |
| OTHERS | |
| Fuel Indicator Gauge | Standard |
| Front Tow Hook | Standard |
| Front & Rear Weights with std. Ballast | Front weights – 15 x 2 |
| Trailer Hitch | 1. Swinging Bar (Optional) |
| 2. Clevis Hitch (Standard) | |
| Roll Over Protection | Standard |
| Canopy | Standard |
| OPTIONAL FEATURES | |
| Tyres |
TURF Front Tyre: 23×8.50 – 12 |
| Front End Loader | Optional |
